| Model | GT-G3-5/7 |
| Sections | 3 |
| Length (mm) | A5000+B7000=C12000mm |
| Belt material | Beck PVK |
| Belt width/thicknessmm (mm) | 800/3.2mm |
| Load bearing of Belt (kg/m²) | 80 (kg/m²) |
| Main/telescopic motor brand | Mord/Mord |
| Main/telescopic motor power | 2.2/0.75KW |
| Frame material/thickness | Manganese steel 6mm/5mm/5mm |
| Transfer type/speed | Chain/45m/min |
| Frequency transformer/PLC | Schneider/Delta |
| Electric box control mode | Both front end & electric box |
| Model | GT-G3-6/8 |
| Sections | 3 |
| Length (mm) | A6000+B8500=C14500mm |
| Belt material | Beck PVK |
| Belt width/thicknessmm (mm) | 800/3.2mm |
| Load bearing of Belt (kg/m²) | 80 (kg/m²) |
| Main/telescopic motor brand | Mord/Mord |
| Main/telescopic motor power | 2.2/0.75KW |
| Frame material/thickness | Manganese steel 6mm/5mm/5mm |
| Transfer type/speed | Chain/45m/min |
| Frequency transformer/PLC | Schneider/Delta |
| Electric box control mode | Both front end & electric box |
