| Model | GT-G5-6/16 |
| Sections | 5 |
| Length (mm) | A6000+B16000=C22000mm |
| Belt material | Beck PVK |
| Belt width/thickness (mm) | 800/3.2mm |
| Load bearing of Belt (kg/m²) | 80 (kg/m²) |
| Main/telescopic motor brand | Mord/Mord |
| Main/telescopic motor power | 4.0/1.5KW |
| Frame material/thickness | Bao Steel 8mm/8mm/6mm/5mm/5mm |
| Transfer type/speed | Chain/45m/min |
| Frequency transformer/PLC | Schneider/Delta |
| Electric box control mode | Both front end & electric box |
