| Model | GT-G4-6/12 |
| Section4 | 4 |
| Length (mm) | A6000+B12500=C18500mm |
| Belt material | Beck PVK |
| Belt width/thicknessmm (mm) | 800/3.2mm |
| Load bearing of Belt (kg/m²) | 80 (kg/m²) |
| Main/telescopic motor brand | Mord/Mord |
| Main/telescopic motor power | 3.0/0.75KW |
| Frame material/thickness | Bao Steel 6mm/6mm/5mm/5mm |
| Transfer type/speed | Chain/45m/min |
| Frequency transformer/PLC | Schneider/Delta |
| Electric box control mode | Both front end & electric box |
| Model | GT-G4-7/14 |
| Sections | 4 |
| Length (mm) | A7000+B14000=C21000mm |
| Belt material | Beck PVK |
| Belt width/thicknessmm (mm) | 800/3.2mm |
| Load bearing of Belt (kg/m²) | 80 (kg/m²) |
| Main/telescopic motor brand | Mord/Mord |
| Main/telescopic motor power | 3.0/0.75KW |
| Frame material/thickness | Bao Steel 6mm/6mm/5mm/5mm |
| Transfer type/speed | Chain/45m/min |
| Frequency transformer/PLC | Schneider/Delta |
| Electric box control mode | Both front end & electric box |
| Model | GT-G4-7.5/16 |
| Sections | 4 |
| Length (mm) | A7500+B16000=C23500mm |
| Belt material | Beck PVK |
| Belt width/thicknessmm (mm) | 800/3.2mm |
| Load bearing of Belt (kg/m²) | 80 (kg/m²) |
| Main/telescopic motor brand | Mord/Mord |
| Main/telescopic motor power | 4.0/1.5KW |
| Frame material/thickness | Bao Steel 6mm/6mm/5mm/5mm |
| Transfer type/speed | Chain/45m/min |
| Frequency transformer/PLC | Schneider/Delta |
| Electric box control mode | Both front end & electric box |
