Applicable scenarios: e-commerce goods to people handling, manufacturing industry handling, electronic industry handling Core advantages:
Driving mode: double wheel differential speed, support in situ rotation, arc turn, U-turn.
Navigation mode: QR code navigation+inertial navigation/texture navigation.
Power supply mode: autonomous charging+manual charging.
Control mode: supports automatic, manual, remote control, and other operations.
Communication mode: WIFI or LTE+low-power IoT.
Load mode: submersible jacking+follow-up.
Human-computer interaction: key+sound light+remote control+display screen.
Safety protection: radar+binoculars+tof+ultrasonic+safety contacts+emergency stop. Match shelf
Minimum shelf size 850 * 850mm
Maximum shelf size 2000 * 1200 * 2400mm
Shelf chassis to the ground: 285mm ± 5mm
| Dimensions | L1570mm*W780mm*H720mm | Orientation accuracy | ±1° |
| Turning radius | ≤1000mm | Stop accuracy | ±10mm |
| Way of communication | 802.11b/g/n/ac | Gradeability | 5° |
| specified load | 1000kg | Running direction | front and rear bidirectional+Rotate in place+arc turn |
| Deadweight | 370kg | Minimum pickup lane | 2200mm(Can be adjusted by independent pallet identification) |
| guide way | laser SLAM Navigation/QR code navigation | Safety | Multi-laser sensor, visual sensor, photoelectric fork foot, safety edge, emergency stop, sound, and light alarm |
| Lift height | 100mm | Battery parameters | 48V 51Ah |
| Load center | 550mm | Charging method | manual/automatic |
| Fork surface minimum ground clearance | 95mm | Charge/discharge cycles | fully charged and discharged1500Second-rate |
| Minimum ground clearance | 20mm | Battery life | full load operation≥8Hour |
| Rated speed | 0.75m/s | Charging time | Charging time after full discharge≤2.5Hour |
